Why TwinTec?
![](https://www.humbersoft.co.uk/wp-content/uploads/2018/11/Twin-Cylinder-Design.png)
Twin Cylinder Design
Guaranteed soft water 24 hours a day.
![](https://www.humbersoft.co.uk/wp-content/uploads/2018/11/Non-Electric.png)
Non Electric
No timers, motors, adjustments or complicated programming.
![](https://www.humbersoft.co.uk/wp-content/uploads/2018/11/Block-Salt.png)
Block Salt
Easy to handle and store.
![](https://www.humbersoft.co.uk/wp-content/uploads/2018/11/High-Flow-Rates.png)
High Flow Rates
Flow rate of 65 litres per minute (with minimal pressure loss) ensures power showers and mega-flow are no problem.
![](https://www.humbersoft.co.uk/wp-content/uploads/2018/11/Accurate-Metering.png)
Accurate Metering
Displacement meters mean accurate regeneration, low salt costs and efficient water usage.
![](https://www.humbersoft.co.uk/wp-content/uploads/2018/11/WRAS-Approved.png)
WRAS Approved
Reliable and fully tested with no annual maintenance.
TwinTec S3 Water Softener
![](https://www.humbersoft.co.uk/wp-content/uploads/2018/11/TwinTC-S3-Water-Softener.jpg)
Dimensions:
Height | 490mm |
Width | 205mm |
Depth | 440mm |
Technical Specification:
Inlet/Outlet Connections | 3/4″ bsp male parallel |
Drain | 3/8″ Outside Diameter Tubing |
Overflow | ½" Hose Connector |
Maximum Working Pressure | 8 Bar |
Minimum Working Pressure | 1 Bar |
Maximum Working Temperature | 20°C |
Minimum Working Temperature | Protect From Freezing |
Salt Storage | 2 x 4kg blocks |
Salt Used Per Regeneration | 250 - 350g |
Regeneration Time | Approx 11 Minutes |
Maximum Flow Rate | 65 L/Min |
TwinTec XL2 Water Softener
![](https://www.humbersoft.co.uk/wp-content/uploads/2018/11/TwinTex-XL2-Water-Softener-1.jpg)
Dimensions:
Softener
Height | 500mm (19 ¾") |
Depth | 440mm (17 ½") |
Width | 250mm (10") |
Cabinet
Height | 390mm (15 ½") |
Depth | 440mm (17 ½") |
Width | 250mm (10") |
Technical Specification:
Inlet/Outlet Connections | 1" BSP Male - ¾ Adaptors |
Drain | ½" Hose Spigot |
Overflow | ½" Hose Spigot |
Maximum Working Pressure | 8 Bar (6 Bar Daytime) |
Minimum Working Pressure | 1 Bar Dynamic |
Maximum Working Temperature | 20°C |
Minimum Working Temperature | Protect From Freezing |
Salt Storage | 24kg (6 x 4kg blocks) |
Salt Used Per Regeneration | 0.9 - 1.3kg |
Water Used Per Regeneration | 37 Litres |
Regeneration Time | 20 Minutes |
Maximum Flow Rate | 80 L/Min |
Pressure Loss | >0.6 Bar at 30 L/Min |
Maximum Daily Capacity @ 300 PPM | 6,444 Litres |
Service Between Regenerations | 1600 - 3200 Litres |
TwinTec XXL Water Softener
![](https://www.humbersoft.co.uk/wp-content/uploads/2018/11/TwinTec-XXL-Water-Softener.jpg)
Dimensions:
Height | 660mm |
Width | 590mm |
Technical Specification:
Inlet/Outlet (BSP Male Parallel) | 1" or ¾ |
Salt Tank Overflow/Drain | ½" Hose Connector |
Maximum Pressure | 8 Bar |
Minimum Pressure | 1 Bar |
Maximum Temperature | 20°C |
Type of Salt | Tablet Only |
Salt Storage | 65kg |
Maximum Flow | 80 L/Min |
Minimum Flow | >10 L/Hour |
Salt Used Per Regeneration | 1300/1600g |
Regeneration Water Volume | 50 Litres |
Approx Flow Rate To Drain | 2.5 L/Min |
Regeneration Time | >20 Minutes Approx |
