Water Softener

Why TwinTec?



Why TwinTec VideoWhy TwinTec Video Hover

TwinTec S3 Water Softener



Dimensions:

Height 490mm
Width 205mm
Depth 440mm
Technical Specification:

Inlet/Outlet Connections 3/4″ bsp male parallel
Drain 3/8″ Outside Diameter Tubing
Overflow ½" Hose Connector
Maximum Working Pressure 8 Bar
Minimum Working Pressure 1 Bar
Maximum Working Temperature 20°C
Minimum Working Temperature Protect From Freezing
Salt Storage 2 x 4kg blocks
Salt Used Per Regeneration 250 - 350g
Regeneration Time Approx 11 Minutes
Maximum Flow Rate 65 L/Min
TwinTec S3 Water Softener VideoTwinTec S3 Water Softener Video Hover

TwinTec XL2 Water Softener



Dimensions:

Softener

Height 500mm (19 ¾")
Depth 440mm (17 ½")
Width 250mm (10")

Cabinet

Height 390mm (15 ½")
Depth 440mm (17 ½")
Width 250mm (10")
Technical Specification:

Inlet/Outlet Connections 1" BSP Male - ¾ Adaptors
Drain ½" Hose Spigot
Overflow ½" Hose Spigot
Maximum Working Pressure 8 Bar (6 Bar Daytime)
Minimum Working Pressure 1 Bar Dynamic
Maximum Working Temperature 20°C
Minimum Working Temperature Protect From Freezing
Salt Storage 24kg (6 x 4kg blocks)
Salt Used Per Regeneration 0.9 - 1.3kg
Water Used Per Regeneration 37 Litres
Regeneration Time 20 Minutes
Maximum Flow Rate 80 L/Min
Pressure Loss >0.6 Bar at 30 L/Min
Maximum Daily Capacity @ 300 PPM 6,444 Litres
Service Between Regenerations 1600 - 3200 Litres

TwinTec XXL Water Softener



Dimensions:

Height 660mm
Width 590mm
Technical Specification:

Inlet/Outlet (BSP Male Parallel) 1" or ¾
Salt Tank Overflow/Drain ½" Hose Connector
Maximum Pressure 8 Bar
Minimum Pressure 1 Bar
Maximum Temperature 20°C
Type of Salt Tablet Only
Salt Storage 65kg
Maximum Flow 80 L/Min
Minimum Flow >10 L/Hour
Salt Used Per Regeneration 1300/1600g
Regeneration Water Volume 50 Litres
Approx Flow Rate To Drain 2.5 L/Min
Regeneration Time >20 Minutes Approx
